Complete set of karaoke system EVOBOX
The EVOBOX home karaoke system is delivered in a branded gift box.
To prevent damage during transportation, EVOBOX is additionally equipped with a shipping box.
What's in the box?
Karaoke system EVOBOX
Bluetooth remote control
RCA to RCA audio cables x 2
HDMI cable
Power Supply
AA batteries, 2 pcs.
User guide
Database of songs and clips
EVOBOX
EVOBOX Plus
TOP-1800
domestic songs
21,000+
domestic songs
TOP-200
foreign songs
100 any songs from the catalog
Evolution available for
free download
14,000+
foreign songs
6,000+
domestic songs
many original video clips
EVOBOX has the ability to purchase any song from the complete EVOLUTION karaoke catalog at a single cost per song.
EVOBOX colors
Black
Gold
Graphite
Ruby
Silver
Ocean
Dimensions and weight
karaoke systems
Height: 49 mm
Width: 198mm
Length: 198 mm
Net weight: 870g
Gross weight: 3 Kg
Control
karaoke system
Bluetooth
remote control
iPad (Evocontrol)
Android (EvoControl)
iPhone (EvoNet)
Android (EvoNet)
Anodized aircraft grade aluminum
Microphone inputs: Balanced TRS 6.3 (Jack) (5), 2 pcs.
Maximum Mic Input Gain: 32.5 dB
Maximum input amplitude: +0.14 dBc (0.788Vrms)
Input Signal to Noise Ratio: -95.9 dB (A-weighted)
Dynamic range: 95.7 dB
Harmonic distortion + noise: 0.0011%
Frequency band: (+/- 0.5 dB) 50 Hz - 20 kHz
Crosstalk: -95.3 dB
Input impedance: 25 kOhm
Audio ADC - Asahi Kasei Microdevices AK5703
Stereo output - RCA (6), 2 pcs.
Output signal-to-noise ratio: 99.3 dB (A-weighted)
Dynamic range: 99.4 dB
Harmonic distortion + noise: 0.005%
Frequency Band: (+/- 0.5 dB) 20 Hz - 20 kHz
Crosstalk: -98.3 dB
Maximum output amplitude: +4.7 dBc (1.34Vrms)
Output Impedance: 470 Ohm
Audio DAC - Asahi Kasei AK4430
Maximum image resolution - 4K UHD (3840 x 2160)
Video: MOV, AVI, MP4, MKV
Sound: WAV, OGG, MP3
Graphic: PNG, JPG, JPEG
Karaoke: EK2
Wi-Fi 802.11ac support. Dual band operation (2.4 GHz and 5 GHz)
Bluetooth 4.1 Low Energy
HDMI 2.0 * (2)
USB Type-A (4) x 2
Gigabit LAN (RJ45) (3)
Power connector (1)
* intended solely for image transmission
SSD capacity:
EVOBOX - 120 GB
EVOBOX Plus - 960 GB
Quad Core Cortex-A53 processor
RAM DDR4 2GB
Graphics Subsystem Mali-T820 MP3 GPU
Power supply: 12V / 2A
Power consumption: 24W
Working temperature range: 0-50 ºC
Transport box dimensions (W × H × D), mm: 313 × 124 × 316
